Description
Condition: New – Open box
Condition Description: New item as seen in the images. No additional items are included in the sale. 30-day warranty Included.
MPN: 3SU1400-1AA10-1BA0
Custom Label: 2-K2F-121313-ZJ-JR
Specifications
| Brand | Siemens |
|---|---|
| Catalog Number | 3SU1400-1AA10-1BA0 |
| Product Type | Contact Module |
| Product Family | SIRIUS ACT 3SU1 Series |
| Contact Configuration | 1 NO (Normally Open) |
| Contact Material | Silver Alloy |
| Connection Type | Screw Terminals |
| Operating Voltage | 5-500V AC/DC |
| Max Current (AC-12) | 10 A @ 24-110V; 8 A @ 230-400V |
| Max Current (AC-15) | 6 A @ 24-110-230V; 3 A @ 400V; 1.4 A @ 500V |
| Insulation Voltage | 500V |
| IP Rating | IP40 (enclosure) / IP20 (terminal) |
| Mounting | Front Plate Mounting |
| Dimensions (H×W×D) | 33.2 × 9.8 × 27.7 mm |
| Mechanical Life | 10,000,000 cycles |
